Yamaha PSR SX900 Keyboard (61-Key Arranger Workstation)

• FSB Keyboard: The newly designed keyboard features heavier initial key resistance and greater key travel, ensuring comfortable playability and expressive performance capabilities.
• Joystick Controller: This allows nuanced and dynamic pitch and modulation control, including rapid trills and expressive pitch bends, with an additional Modulation Hold feature for sustained effects.
• Expansive Soundfield Speakers: Yamaha's advanced speaker system delivers a full, balanced sound that remains clear and consistent regardless of audience position, elevating live performance quality.
• Studio Quality Output: A new Digital Audio Converter (DAC) produces highly detailed sound with a wide frequency response for professional-grade audio output during recording and live sessions.
• Authentic Voices: With over 1,393 instrument sounds, the PSR-SX900 gives players an extensive range of tones for authentic and expressive performances.
• Styles: Offering a vast range of rhythmic backing patterns, the keyboard allows for creating full-band arrangements, aiding in songwriting and performance variety.
• Playlist and Registration Memory: This feature serves to manage and recall song settings quickly, enhancing workflow efficiency during performances.
• Sub Output: Four sub line-out connections provide flexibility in sound routing for live setups, allowing separate control over specific instruments or click tracks.
• Chord Looper: This allows recording and looping of chord sequences, freeing up the player's hands for complex passages or live sound manipulation.
• Touch Screen/GUI: A 7" touch display paired with a new graphic interface allows for intuitive navigation and control over the keyboard's features.
• Assignable Function: Customize functionalities across six panel buttons, live control knobs, and pedals for quick access to essential features during live play.
• Style Section Reset: Instantly restart the accompaniment at the beginning of a bar, useful when playing music with complex arrangements or varying time signatures.
• Audio Link Multi Pad: Extend creative expression by triggering user-recorded rhythmic and melodic loops from the multi pads during performances.
• Voice & Style Expansion Packs: Personalize your keyboard with additional content from various global styles and create unique voices based on your sample library using the Yamaha Expansion Manager.
• Applying Effects to the Microphone Sound: Vocalists can enhance their voice with various effects, including Vocal Harmony, or create layered sounds using the Synth Vocoder.

Color/Finish

Body

• Color: Black

Size/Weight

Dimensions

• Width: 1017 mm (40")
• Height: 139 mm (5.5")
• Depth: 431 mm (17")

Weight

• Weight: 11.5 kg (25.35 lb)

Packing Box

• Width: 1,181 mm (46-1/2")
• Height: 251 mm (9-7/8")
• Depth: 524 mm (20-5/8")

Control Interface

Keyboard

• Number of Keys: 61
• Type: Organ (FSB), Initial Touch
• Touch Response: Normal, Soft 1, Soft 2, Hard 1, Hard 2

Other Controllers

• Joystick: Yes
• Control Knobs: 2 (assignable)

• Display Type: TFT Color Wide VGA LCD
• Size: 800 x 480 dots (7 inch)
• Touch Screen: Yes
• Color: Color
• Language: English, German, French, Spanish, Italian

Panel

• Language: English

Voices

Tone Generation

• Tone Generating Technology: AWM Stereo Sampling

Polyphony

• Number of Polyphony (Max.): 128

Preset

• Number of Voices: 1337 Voices + 56 Drum/SFX Kits
• Featured Voices: 252 S.Art!, 54 Mega Voices, 31 Sweet! Voices, 87 Cool! Voices, 131 Live! Voices, 24 Organ Flutes!

Compatibility

• XG: Yes (for Song playback)
• GS: Yes (for Song playback)
• GM: Yes
• GM2: Yes

Expandability

• Expansion Voice: Yes (approx. 1 GB)

Editing

• Voice Set: Voice Set
• Part: Right 1, Right 2, Right 3, Left

Effects

• Reverb: 59 Presets + 30 User
• Chorus: 106 Presets + 30 User
• DSP: 322 Presets (with VCM) + 30 User
• Insertion Effect: 1-8: 322 Presets (with VCM) + 30 User
• Master Compressor: 5 Presets + 30 User
• Master EQ: 5 Presets + 30 User
• Part EQ: 28 Parts
• Others: Mic/Guitar Effects: Noise Gate, Compressor, 3 Band EQ, Vocal Effect: 23
• Arpeggio: Yes
• Vocal Harmony: Vocal Harmony: 54, Synth Vocoder: 20
• Number of User Settings: 60 *The number is the total of Vocal Harmony and Synth Vocoder

Accompaniment Styles

Preset

• Number of Preset Styles: 525
• Featured Styles: 463 Pro Styles, 46 Session Styles, 10 DJ Styles, 6 Free Play
• Fingering: Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard
• Style Control: INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3

Other Features

• One Touch Setting (OTS): 4 for each Style
• Chord Looper: Yes
• Style Section Reset: Yes
• Expandability: Expansion Style: Yes (Internal Memory)
• Compatibility: Style File Format, Style File Format GE

Songs

Preset

• Number of Preset Songs: 5 Sample Songs

Recording

• Number of Songs: Unlimited (depends on the drive capacity)
• Number of Tracks: 16
• Data Capacity: Approx. 3 MB/Song
• Recording Function: Quick Recording, Multi Recording, Step Recording

Compatible Data Format

• Playback: SMF (Format 0 & 1), XF
• Recording: SMF (Format 0)

Multi Pads

Preset

• Number of Multi Pad Banks: 329 Banks x 4 Pads
• Audio Link: Yes

Functions

Registration

• Number of Buttons: 8
• Control: Registration Sequence, Freeze

Playlist

• Number of Records: 2500 (max.) Records per Playlist file

Lesson/Guide

• Lesson/Guide: Follow Lights, Any Key, Karao-Key, Your Tempo
• Search: Registration Bank

Demo/Help

• Demonstration: Yes

Overall Controls

• Metronome: Yes
• Tempo Range: 5 - 500, Tap Tempo
• Transpose: -12 – 0 – +12
• Tuning: 414.8 – 440 – 466.8 Hz
• Octave Button: Yes
• Scale Type: 9 types

Bluetooth

• Bluetooth: Yes (Audio) * May not have this functionality depending on the country

Miscellaneous

• Direct Access: Yes
• Text Display Function: Yes
• Wallpaper Customization: Yes
• Display Out: Yes (by using a commercially available USB display adaptor) * For a list of compatible devices, access the “Yamaha Downloads” website.

Voices

• Harmony/Echo: Yes (with Arpeggio)
• Panel Sustain: Yes
• Mono/Poly: Yes
• Voice Information: Yes

Styles

• Style Creator: Yes
• OTS Information: Yes

Songs

• Score Display Function: Yes
• Lyrics Display Function: Yes
• Song Creator: Yes

Multi Pads

• Multi Pad Creator: Yes

Audio Recorder/Player

• Recording Time (max.): 80 minutes/Song
• Recording: .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (44.1 kHz sample rate,128/256/320 kbps, mono/stereo)
• Playback: .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz sample rate, 64-320 kbps and variable bit rate, mono/stereo)
• Lyrics Display Function: Yes (.mp3 only)
• Time Stretch: Yes
• Pitch Shift: Yes
• Vocal Cancel: Yes

Storage and Connectivity

Storage

• Internal Memory: Yes (approx. 4 GB)
• External Drives: USB Flash Memory (via USB to DEVICE)

Connectivity

• Headphones: Yes
• FOOT PEDAL: 1 (SUSTAIN), 2 (ARTICULATION), Function Assignable
• Microphone: Microphone/Guitar x 1
• MIDI: IN, OUT
• AUX IN: Stereo mini jack
• LINE OUT: MAIN OUTPUT (L/L+R, R), SUB (AUX) OUTPUT (1,2 (L/L+R, R))
• USB TO DEVICE: Yes (x 2)
• USB TO HOST: Yes

Amplifiers and Speakers

• Amplifiers: (15 W + 10 W) x 2
• Speakers: 13 cm x 2 + 2.5 cm (dome) x 2

Power Supply

• Power Supply: PA-300C or an equivalent recommended by Yamaha
• Power Consumption: 24 W
• Auto Power Off Function: Yes

Accessories

• Included Accessories: Owner's Manual, Online Member Product Registration, Music Rest, AC Adaptor(may not be include depending on your area. Check with your Yamaha dealer.)

• Music Rest: A stable and durable stand for your sheet music, ensuring a comfortable and seamless playing experience.
• Power Adapter: PA-300C
• Owner's Manual: Your comprehensive guide to the functionalities, maintenance, and care of your Yamaha piano.
• 1-Year Warranty for Total Assurance: Your Yamaha piano comes with a rock-solid guarantee against material and craftsmanship defects, valid for one full year after your purchase date.
